Atlas Strategy Series User Manual

– 3 – AtlasSound.com
Specifications are subject to change without notice.
Owner’s Manual Surface Mount Loudspeakers
1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A.
Telephone: 800.876.3333 • Fax: 800.765.3435
Down Firing
The SM Series speaker systems also work well in a down firing configuration for spaces utilizing open beam ceilings such as offices,
restaurants and warehouses. When determining speaker spacing in down-firing installations, refer to the following chart:
Note: Using the above spacing suggestions will maintain good, even high frequency coverage, which translates into excellent intelligi-
bility for voice reproduction and high fidelity music reproduction. To find out more about the formulas used to determine ceiling
speaker spacing, check out the book Sound System Engineering by Don and Carolyn Davis. To find out more about the limits of
wide dispersion loudspeakers, download the Atlas Sound white paper on the subject at
http://www.atlassound.com/Support/WhitePapers.aspx .
Ceiling
Height
Speaker Spacing
MAX SPL @ Highest Tap
(with the Listener @ 3.5')
SM42T SM52T SM82T SM42T SM52T SM82T
8'
6' 6' – 97dB 102dB –
9'
8' 8' – 96dB 101dB –
10'
9' 9' 6' 94dB 99dB 104dB
11'
10' 10' 6.5' 93dB 98dB 103dB
12'
12' 12' 7.5' 92dB 97dB 102dB
13'
13.5' 13.5' 8.5' 91dB 96dB 101dB
14'
15' 15' 9.5' 90dB 95dB 100dB
15'
16' 16' 10' 89dB 94dB 99dB
16'
– 17.5' 11' – 93dB 98dB
17'
– 19' 12' – 93dB 98dB
18'
– 20.5' 13' – 92dB 97dB
19'
– 22' 14' – 92dB 97dB
20'
– 23' 15' – 91dB 96dB
25'
– – 19' – – 94dB
30'
– – 24' – – 92dB
SM42T = 90° Nominal Coverage at 2kHz
SM52T = 90° Nominal Coverage at 2kHz
SM82T = 65° Nominal Coverage at 2kHz
