Installation
Fixed Install
The SM Series speaker systems include a versatile yet simple U-bracket designed to provide easy vertical or horizontal installation on
just about any surface. The speaker may be installed using screws or bolts placed through the "Keyhole" shaped holes in the mounting
bracket. The center
5
⁄8"-27 hole allows wire to exit through the bracket when wall mounting, for a neat installation. The unused inserts
on the bottom and top of the SM82T are M5 and on the rear of the SM52T are
1
⁄4"-20. These openings can be used with forged eyebolt
and an approved safety cable (wire rope sling) where redundant support is required for seismic considerations.
These parts are available through multiple sources.
Eyebolt, Lifting With Shoulder, Steel, Plain Finish,
1
⁄4-20 In Thread Size, 1" Thread Length, 1" Shank Length,
17
⁄32" Shoulder Diameter,
5
⁄32" Shoulder Length,
3
⁄4" Eye Inside Diameter, 1
1
⁄4" Eye Outside Diameter, 2
3
⁄8" Overall Length, 500 Lb Working Load Limit
Galvanized Steel Cable Spool,
1
⁄8"
Sleeve N Thimble
™
Kit for
1
⁄8" Cable
Swage It Tool for
1
⁄16",
3
⁄32", and
1
⁄8" - Cable Size
The mounting knobs included with the Surface Mount Speaker products may be easily interchanged with standard,
1
⁄4"-20 vandal
proof hardware.
TORX Drive Button Head
1
⁄4" Machine Screw, Tamperproof,
1
⁄2" Length
One-Way Round Head
1
⁄4" Machine Screw, Tamperproof,
1
⁄2" Length
Spanner Flat Head
1
⁄4" Machine Screw,Tamperproof,
1
⁄2" Length
Overhead Suspension
CAUTION: Suspending any object is potentially dangerous and should be attempted only by individuals who have a thorough knowl-
edge of the techniques and regulations of rigging objects overhead using ONLY hardware approved for this type of installation. Atlas
Sound strongly recommends that Strategy Series Surface Mount enclosures only be suspended overhead when taking into account all
current national, federal, state, and local regulations. It is the responsibility of the installer to insure that the speaker is installed accord-
ing to those regulations. If the Strategy Series Surface Mount speaker is suspended, Atlas Sound strongly recommends that the sys-
tem be inspected at least once a year. If any sign of weakness or damage is detected, remedial action should be taken immediately.
