– 9 – AtlasSound.com
Specifications are subject to change without notice.
Owner’s Manual Surface Mount Loudspeakers
1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A.
Telephone: 800.876.3333 • Fax: 800.765.3435
Specifications
SM82T
Frequency Response 65Hz – 20kHz (±3dB)
Low Frequency 3dB Down Point 65Hz
Usable Low Frequency Limit (10dB Down Point) 51Hz
Power Handling in 70.7V / 100V Systems 2 – 60 Watts selectable in 3dB Steps
Power Handling in 8Ω Switch Position 150 Watts RMS
Sensitivity (1W / 1M) 92dB
Nominal Coverage Angle 65°H x 65°V
Transducer Complement
High Frequency 1" Exit Compression Driver
Low Frequency 8" Hycone Treated Woofer
Crossover Frequency 2.2kHz
Crossover Slope 12dB / Octave
Input Connections 2 Pole Barrier Strip with Weather-resistant Cover
Driver Protection (High Frequency) Atlas Sound Poly Guard™
Materials UV-Resistant Talc Impregnated Polypropylene Injection Molded Weatherproof
Enclosure. (Black or White Finish) Perforated Powder Coated Aluminum Grille
Matches Enclosure Color
Weight (Less Bracket) 18.08lbs. (8.2kg)
Height 16
1
⁄2" (41.9cm)
Width 9
1
⁄16" (23.0cm)
Depth 8
7
⁄16" (21.49cm)
