4929B–AUTO–01/07

ATA6264 [Preliminary]

The following settings can be made at the initial programming:

MSBit LSBit

VR1 VR2 VR3 VR4 EXT ISO/LIN Parity Lock bit

Table 5-2. Initial Programming Settings

VR1 VR2 VR3 VR4 VCORE VPERI VSAT

0 0 0 0 All regulators deactivated (default)

0 0 0 1 1.88V 3.3V 7.8V

0 0 1 0 1.88V 3.3V 9.1V

0 0 1 1 1.88V 3.3V 10.4V

0 1 0 0 2.5V 3.3V 7.8V

0 1 0 1 2.5V 3.3V 9.1V

0 1 1 0 2.5V 3.3V 10.4V

0 1 1 1 1.88V 5V 7.8V

1 0 0 0 1.88V 5V 9.1V

1 0 0 1 1.88V 5V 10.4V

1 0 1 0 2.5V 5V 7.8V

1 0 1 1 2.5V 5V 9.1V

1 1 0 0 2.5V 5V 10.4V

1 1 0 1 5V 5V 7.8V

1 1 1 0 5V 5V 9.1V

1 1 1 1 5V 5V 10.4V

Set to 0 Set to 1

EXT No external transistor at VPERI (default) External transistor at VPERI applied

Set to 0 Set to 1

ISO/LIN ISO9141 mode is activated at K1 (default) LIN mode is activated at K1
