Atmel ATA6264 - Package Information; P-TQFP 44 Package Dimensions

79
4929B–AUTO–01/07
ATA6264 [Preliminary]
26. Package Information
25. Ordering Information
Extended Type Number Package Remarks
ATA6264-ALTW P-TQFP44 Tray
ATA6264-ALQW P-TQFP44 Taped and reeled
specifications
according to DIN
technical drawings
10±0.05
12±0.2
8
12 22
44 34
33
0.2
23
1
11
0.8
Issue: 1; 11.05.06
Drawing-No.: 6.543-5131.01-4
0.1±0.05
0.6±0.15
1.4±0.05
Dimensions in mm
(acc. JEDEC OUTLINE No. MO-112)
Package: P-TQFP 44
0.37-0.07
+0.08
