ATA6264 [Preliminary]
ESD classification at pins connected to
devices outside the ECU (IASG1 to
IASG5)
Human body model (HBM) HBM
AEC Q100-002
±3000 V
ESD classification at pins connected to
devices outside the ECU (K1 and K2)
Human body model (HBM) HBM
AEC Q100-002
±2500 V
General ESD classification for all other
pins
Human body model (HBM)
Charged device model (CDM) – no corner
pins
Charged device model (CDM) – corner
pins
HBM
AEC Q100-002
CDM
ESD STM5.3.1-1999
±1500
±500
±750
V
V
V
3. Absolute Maximum Ratings (Continued)
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. This is a stress rating
only and functional operation of the device at these or any other conditions beyond those indicated in the operational sections of this
specification is not implied. Exposure to absolute maximum rating conditions for extended periods may affect device reliability.
All voltages are referenced to an ideal ground level of an ECU connected to the GNDA, GNDB and GNDD pins.
Parameters Remark Minimum Maximum Unit
