Atmel ATF16V8B - Pin Configurations

2
0364J–PLD–7/05
ATF16V8B/BQ/BQL
Figure 1-1. Block Diagram
2. Pin Configurations
Table 2-1. Pin Configurations (All Pinouts Top View)
Pin Name Function
CLK Clock
I Logic Inputs
I/O Bi-directional Buffers
OE
Output Enable
VCC +5V Supply
Figure 2-1. TSSOP Figure 2-2. DIP/SOIC
Figure 2-3. PLCC
1
2
3
4
5
6
7
8
9
10
20
19
18
17
16
15
14
13
12
11
I/CLK
I1
I2
I3
I4
I5
I6
I7
I8
GND
VCC
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I9/OE
1
2
3
4
5
6
7
8
9
10
20
19
18
17
16
15
14
13
12
11
I/CLK
I1
I2
I3
I4
I5
I6
I7
I8
GND
VCC
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I9/OE
4
5
6
7
8
18
17
16
15
14
I3
I4
I5
I6
I7
I/O
I/O
I/O
I/O
I/O
3 2 1
20 19
9 10 11 12 13
I8
GND
I9/OE
I/O I/O
I2 I1 I/CLK VCC I/O
