Technical Information
Electrical Specications
ThermoBoost
24 kw
Heating elements 3
Watts 24,000
Kilowatts 24 kW
Voltage 240 V
Circuit Breaker Amperage 3 x 40 A
Breaker/Relay 3 x double-pole
Total Connection Load 100 A
Cable Size (minimum) 3 x 8 AWG
Plumbing Specications
Minimum water ow to activate unit 0.5 gpm
Working pressure 0.5–10 bar (7–145 psi)
Tested pressure 20 bar (290 psi)
Water connections 3/4" NPT
Flow Rate
Temperature Rise
Δt (°F)
Flow Rate (gpm)
ThermoBoost
24 kw
81 2
74 2.2
63 2.5
54 3
45 3.6
36 4.5
Physical Dimensions
Height Width Depth Weight
13
3
/
8
in.
(340 mm)
17
3
/
8
in.
(440 mm)
5
1
/
4
in.
(135 mm)
17 lbs
(7.7 kg)
3
