33. Wiring diagram connection of the boilers DCxxS(X),
CxxS(T), ACxxS, KCxxS, DCxxRS with exhaust fan, model
with 6-pin connector and two AD02 modules - to control
extraction fan of the boiler and pump in the boiler circuit
from burner control unit AC07X (R and R2)
