Atmos Multi - Connecting the Weather Dependent Control; Connecting the Cable Connector K4 b; Connecting the Outside Sensor; Connecting the CH Return Sensor

ATMOS MULTI Weather Dependant Control
Page 3
Installation Manual for Weather Dependent Control
List of Contents
Contents of package
1. Connecting the Weather Dependant Control
1.1 Connecting the cable connector K4b
1.2 Connecting the outside sensor
1.3 Connecting the CH return sensor
2. Set-up and Function of the Weather Dependant Control
2.1 User Program
2.2 Installer Program
2.3 How the Weather Dependant Control works
Contents of package:
• Outside sensor (excluding cable)
• Screw with wall plug
• Return sensor with 3 metre cable (casing with copper strip)
• Cable tie for return sensor (x2)
• Cable glands PG7 incl. nut (x2)
• Cable connector K4b
• Connection sticker
• Installation manual
Please note
The Atmos Multi is supplied with.
• Two holes of 13mm for the PG7 cable glands
• Holes to fit the cable connector
• A cable socket on the controller to take the K4b cable plug
