M
Running capacitor
220VAC
U1
U2
Z1
Z2
Starting capacitor
Centrifugal switch
Main winding
Secondary winding
220VAC
U1
U2
Z1
Z2
M
Starting capacitor
Centrifugal switch
Main winding
Secondary winding
Internal wiring of single phase motor with double capacitors is as below:
Figure 4-5 Starting mode: Internal wiring of motor with single capacitor
Figure 4-6 Internal wiring of motor with double capacitors
GK3000 User Manual
-9-
