PAGE 21
TROUBLESHOOTING: DRILLMASTER ENGINE DRILLS
SHARPENING WOOD AUGERS
PROBLEM CAUSE ACTION
1. Auger will not turn Blunt auger, must be sharp especially for large holes over Sharpen – see instructions below.
at all 19mm (
3
/4”). Always when drilling, drill 50mm then reverse
out to clean shavings from hole.
2. Auger will not turn Not enough power. Check carby adjustment tune motor. Sharpen auger or replace.
at all Blunt auger or worn out, not cleaning hole of wood chips by
reversing and cleaning holes every 50mm or less. Incorrect
side clearance on auger.
3. Drill unit appears not 1. Type of timber soft so auger does not grip to allow unit Small diameters to 13mm (5/8”) may cause this problem.
to reverse auger to to reverse. Drill and reverse every 50mm.
clean out hole of
2. Reverses and unjams very quickly. Very hard to see instant
shavings.
automatic reverse changing to forward drilling.
(R.H. rotation)
4. Jumping out of gear Worn clutch dogs. Blunt auger. Replace.
5. Safety issues. Not Not reading manual. Do not take risks when using equipment. Read manual
using equipment. thoroughly and ensure you understand. Before each work
Read manual and period check engine drill and ensure all screws are tight.
ensure you Ensure it is working correctly, auger does not turn when engine
understand all. idling and fuel tank is filled.
The best hardwood auger is the Atom chisel tip auger with
4 cutting edges (ie 2 longitudinal cutting edges and 2 radial
cutting edges).
SHARPENING ATOM AUGERS WITH
ROUNDED EDGES
Use a small half round file or 3/16 Round file. Carefully file
inside the shaped curve of the cutting edges.
If correctly sharpened, the cutting edges will be as sharp
as saw chain teeth. Once they become dull they should
be resharpened as described.
Never file the outer edges of the auger.
Atom Hard Chisel Tip Augers are the perfect partner for
Atom engine driven drills.
PART
NUMBER
DESCRIPTION
30010 3/8” (10mm) diameter x 12” (300mm) long
30011 7/16” (11mm) diameter x 12” (300mm) long
30013 1/2” (13mm) diameter x 14” (360mm) long
30014 9/16” (14mm) diameter x 14” (360mm) long
30016 5/8” (16mm) diameter x 14” (360mm) long
30018 11/16” (18mm) diameter x 14” (360mm) long
30019 3/4” (19mm) diameter x 14” (360mm) long
30022 7/8” (22mm) diameter x 14” (360mm) long
30025 1” (25mm) diameter x 14” (360mm) long
30028 1 1/8” (28mm) diameter x 14” (360mm) long
30032 1 1/4” (32mm) diameter x 14” (360mm) long
Extra Long Augers
30116 5/8” (16mm) diameter x 30” (760mm) long
30119 3/4” (19mm) diameter x 30” (760mm) long
30122 7/8” (22mm) diameter x 30” (760mm) long
30125 1” (25mm) diameter x 30” (760mm) long
Atom augers are available in the following diameters and lengths:
