KEY # PART # DESCRIPTION
45 43953 R.H. AV MOUNT
46 43954 MAIN HANDLE BRACKET
47 43955 HANDLE AV RUBBER
48 43961 PRO L.H HANDLE
49 43963 RH HANDLE SUIT RUBBER GRIP
50 43965 HONDA AIR DEFLECTOR(GX35)
51 43978 PRO SHAFT (USES FLANGED NUT)
52 43980 FLANGE BUSH SPACER
53 43990 MANUAL HONDA MODEL 506
54 44003 HANDLE KNOB w/nut (44006 + 44075)
55 44010 PRO THROTTLE CABLE ASSY
56 44012 CORRUGATED LOOM 400mm
57 44016 SPACER 8.35MM
58 44062 HANDLE CROSS BRACE
59 44064 HANDLE BOLT HEX PIECE BLACK
60 44074 “HANDLE BOLT 1/4”” X 6"” BSW”
61 44075 BLACK HANDLE KNOB (refer Key #54)
62 44085 TRIGGER COVER W/OUT SLOT
63 44165 SWITCH WIRE 505/506 HONDA
64 44301 PRO AV2 WHEEL ARM
65 44302 HT ADJ PIN
66 44303 PRO AV2 HT ADJ HANDLE
67 44304 “WHEEL AXLE BOLT 3/8”” x 5.5”
68 44305 SEALED BEARING 28x8x12.8mm
69 44307 WHEEL AXLE TUBE SPACER 94.35mm
70 44308 PRO AV2 DEBRIS LIMITER
71 44309 PRO AV2 DEBRIS FLAP
72 44310 WHEEL HUB CAP
73 44311 PRO AV2 MAIN CASING
74 44312 PRO CLUTCH DRUM CUP(32mm LONG)
75 48002 HONDA GX35 ENGINE
76 48010 HONDA EXHAUST OUTLET (GX35)
77 48100 OIL 100ml (for Honda GX-31)
78 44060 HANDLE TUBE RH
79 44061 HANDLE TUBE LH
80 44440 ROCKER ON/OFF SWITCH
81 50650 ATOM LAWN EDGER LABEL
82 43452 ADJUSTING ARM SPRING
83 44087 RIGHT HANDLE TRIGGER ASSEMBLY
* 43935 CABLE ADJUSTER PIN
* 44005 BRASS 6.3mm QC TERMINAL
* ITEMS NOT SHOWN ON DIAGRAM
KEY # PART # DESCRIPTION
1 40650 SCREW M5 x 36mm
2 40652 NUT NYLOC 5mm
3 40835 N.BEARING 32 x 10 x 12 W/SEAL
4 40838 HEX SCREW 6MM x 19MM
5 40906 “O” RING 64 x 1.75mm”
6 42111 SEALS NYLON OD27.2 x ID12.60
7 42112 FELT SEAL
8 43105 CUTTER BLADE SET (form & straight)
9 43108 BEARING 37 x 12 x 12
10 43109 BLADE COVER SUPPORT
11 43110 BLADE COVER
12 43112 BLADE DRUM
13 43114 BLADE SHAFT DRIVE
14 43115 BLADE WASHER SMALL
15 43116 BLADE WASHER LARGE
16 43122 CROWN GEAR L/E
17 43125 SPACER 15.5MM
19 43127 WARNING LABEL HOT MOTOR
20 43128 WARNING LABEL BLADE COVER
21 43133 WARNING LABEL HANDLE
22 43155 MAIN BODY SHIELD (N)
23 43163 FLANGE NUT 3/8 UNC
24 43172 NUT NYLOC 3/8
25 43173 NUT M12 X 1.75
26 43176 PINION GEAR LONG 25.4mm
27 43179 BEARING SCREW M5 X 39
28 43198 TRIGGER COMP.SPRING
29 43199 “SPRING,SMALL”
30 43218 FLAT WASHER 9.77x19.05x1.6 Z/P
31 43288 THROTTLE TRIGGER
32 43292 THROTTLE INTERLOCK
33 43406 LABEL PROFESSIONAL
34 43419 LABEL MODEL 506
35 43484 WASHER 22.43 x 5.94 Z/P
36 43719 DEBRIS DEFLECTOR SPRING
37 43765 WHEEL ONLY
38 43790 SCREW 5.5mm for plastic
39 43860 BEARING 32x10x12 + 4mm
40 43910 DUST PLUG RED
41 43922 RUBBER HANDLE GRIP
42 43941 MAIN BODY COVER(new)
43 43951 PRO ROUND AV RUBBER
44 43952 L.H. AV MOUNT
lll ATOM MODEL 506 LAWN EDGER PARTS LIST
