Atomic 3000 LEDSTROBE - DMX Reset and Display Modes; Art Net DMX and Language Settings; Default Settings and System Info; DMX LIVE and Test Functions

7
DMX Reset
off
Forbid Rest by DMX
on
Rest by DMX
Display
Sleeping display
mode
After 30 seconds, turn off the screen and press
any button to wake up
Not sleeping
Don’t turn off the screen
Error Mode
normal
Any errors detected are displayed on the reset
screen
silent
The error message is not displayed in the screen.
You need to see it in the error table.
Art Net Dmx
shutdown
After the shutdown, receive the control DMX512
signal
opening
After opening, the art net signal is received, and
the control DMX512 is not received
language
Chinese
Interface Language is Chinese
English
Interface Language is English
Default
setting
Factory
Default
Loading
Restore all settings to factory defaults
Info
Boot time
Total boot time
Displays the total operating time
despues de
manufacture
Current boot time
Current boot time displays
Reset Table X time
Counter clear→ Yes/ No Reset counter clear
Software
version
X.X.X
Displays the current program software version
RDM UID
4D50:XXXXXXXX
Display unique RDM ID
Fan speed
Basic fan X RPM
Displays the current speed of the basic fan 1,
NA,0-10000 RPM
temperature
LED temperature
Current temperature, last maximum
temperature, historical maximum temperature
DMX LIVE
Rate
XX Hz
DMX transmission speed
，
live , In seconds
Quality
0-100%
Percentage of error packets received
，
live
Start code
0-255
The decimal value of the DMX start code，live
Channel [Y] X
[Y] 0-255
Display DMX values   (x) on each channel (y)
TEST
LEDS test
Static beam
Test white LEDs at low intensity
Flash beam
White LED test
Beam close
White LEDs off
R AURA
Try red background LEDs
G AURA
Try green background LEDs
B AURA
Test Blue background LEDs
Handbook
control
Reboot
Reboot fixture
Channel [Y]X
Send DMX value [Y] on channel X
...
......
Service
Error table
Displays any valid errors
Fan clear
OFF / ON stop fan
