Atomic AMZ SERIES - Attaching Servo Mount; Attaching Spur gear & Motor gear

Attention:
!
Motor
7
7
Attaching Servo Mount
2x4PM
2x4KM
x5
x2
1.5x6PB
x1
8
8
Attaching Spur gear & Motor gear
2x4PM
2x4KM
2x4KM
2x4KM
2x4PM
1.5x6PB
Servo
(AMZ-OP024)
Servo Mount A
Servo Mount B
Steering System
Linkage assembly
1.5x11 set screw
2.5mm Ball end
Linkage Ball A
Servo horn
1.5x11
Set screw
x1
Quick
Smooth
Steering Respond
!
Attention:
Installation direction
chamfer
Planar
chamfer
Planar
!
Motor
Motor pinion
Spur gear
5x7x1mm
O-ring
2x4KM
x4
5x7x1mm
O-ring
x1
Servo assembly
P.4
!
 14 15 16 17 18
54 5.70 5.36 5.06
56 6.75 6.30 5.91 5.56 5.25
58 7.53 6.99 6.53 6.12 5.76 5.44
Motor Pinion
Spur Gear
(5.91 is recommended for 5000KV motor)
( )
Spur gear
x
1.69
Motor gear
= Gear ratio
Carefully adjust
the position of
pinion, make sure
it does not touch
the front belt.
