Atomic G01342W - Hardware Identifier

HARDWARE IDENTIFIER
( To Scale)
©
2012 Escalade Sports
For Customer Service Call 1-888-996-2729
3
All Rights Reserved.
H1 - 6mm x 22mm
Allen Head Bolt
(16 pcs)
H2 - 6mm x 19mm
Flat Washer (16 pcs)
H3 - 3mm x 28mm
Phillips Flat Head
Screw (8 pcs)
H4 - 4mm x 12mm
Phillips Round Head
Screw (84 pcs)
H5 - 3mm x 28mm
Phillips Washer Head
Screw (18 pcs)
(Not to Scale)
H6 - 4mm x 12mm
Phillips Flat Head
Screw (6 pcs)
H7 - 4mm x 51mm
Phillips Flat Head
Screw (12 pcs)
H8 - 4mm x 51mm
Zinc - Phillips Flat Head
Screw (4 pcs)
T1 - Allen Wrench
(1 pc)
ACCESSORIES IDENTIFIER
( Not to Scale)
A1- Soccer Ball (4 pcs)
!
WARNING:
CHOKING HAZARD
Small parts.
Not for children under 3 yrs.
