HARDWARE IDENTIFIER
(To Scale)
P1 - Pool Table (1)
(Red Cloth)
© 2013 Escalade Sports
For Customer Service Call 1-886-996-2729
P4 - Left Leg (2)
P3 - Right Leg (2)
P2 - Hockey Table
with C1 Blower Motor (1)
All Right Reserved.
H14 - Leg
Leveler (4)
H3 - 3.5 x 32mm Phillips
Washer Head Screw (8)
H1 - 4 x 44mm Phillips
Flat Head Screw (20)
H7-Barrel Nut (8)
H4 - 8 x 28mm
Hex Head Bolt (8)
H6 - 8 x 63mm
Hex Head Bolt (8)
H5 - 8 x 19mm
Flat Washer (28)
H8 - 8 x 200mm Hex Head Bolt (4)
H10 - Male
Pivot Assembly (2)
H12 - M10 x 25mm
Flat Washer (4)
H9 - 4 x 25mm Phillips
Flat Head Screw (6)
H2 - 4 x 38mm Phillips
Flat Head Screw (34)
H13 - M10
Hex Nut (2)
H19 - 4 x 44mm Phillips
Flat Head Screw (24)
H15 - 4 x 12mm Phillips
Round Head Screw (2)
H16 - 3 x 16mm Phillips
Washer Head Screw (14)
(Not to Scale)
(Not to Scale)
H11 - M10
Acorn Nut (2)
H18 - 4 x 44mm Phillips
Washer Head Screw (4)
H17 - 4 x 50mm Phillips
Flat Head Screw (12)
PARTS IDENTIFIER
(Not to Scale)
!
WARNING:
CHOKING HAZARD
Small parts.
Not for children under 3 yrs.
H20 - 3 x 15mm Phillips
Flat Head Screw (4)
T1 - Wrench (1)
(Not to Scale)
