Atomos Connect User Manual

Specifications
• HDMI input resolution up to 4Kp30.
• USB output resolution up to 1080p60 (YUV.JPEG).
• Supports 8/10/12-bit deep color.
• Supports certied AWG26 HDMI cables up to 15 meters.
• Supports popular acquisition software on Windows,
Android & Mac OS.
• Conforms to USB Video and UVC standard.
• Conforms to USB Audio UAC standard (L-PCM format).
• No external power required.
• Maximum working current 0.4A / 5V DC.
• Operating temperature range -10 to +55 °C.
• Dimensions (L x W x H) 64 x 28 x 13mm.
• Weight 21.4g.

Atomos Connect Specifications

General

Audio Input	Embedded SDI/HDMI
Audio Output	Embedded SDI/HDMI
Ports	HDMI, SDI, Ethernet
Operating Temperature	Up to 40°C
Video Input Resolution	4K
Video Output Resolution	4K
