2
Guide d'installation
Étape 2 : Choisissez les diérents engrenages à installer en fonction des éléments gravés.
Engrenage 1： 10mm≤ d ≤20mm
Engrenage 3： 40mm≤ d ≤50mm Engrenage 4：50mm≤ d ≤80mm
Engrenage 2： 30mm≤ d ≤40mm
