Atosa MCF8601GR - Technical Parameters; Top Mount Reach-Ins Specifications

19
Our products have been modified precisely before leaving
factory, so to avoid damaging compressor unit or other
malfunctions, users mustn’t modify the microcomputer
parameters privately.
Technical Parameters
Top Mount Reach-Ins
Model code Power source (V)
Rating frequency(Hz)
Input power (w) Rated current(A)
Temperature range (℉) Refrigerant Amount(oz) Dimension (in)
Volume (cu.ft)
MCF8601GR 115 60 610 6.3 -8~-1 R290 4.2 28.7×33.3×81.3 21.4
MCF8602GR 115 60 935 8.6 -8~-1 R290 5.3 51.7×33.3×81.3 43.16
MCF8603GR
115/208-
230
60 1360 6.2 -8~-1 R290 5.3 77.8×33.3×81.3 64.88
MCF8604GR 115 60 250 2.1 +33~+45 R290 3.9 28.7×33.3×81.3 21.4
MCF8605GR 115 60 370 3.2 +33~+45 R290 4.9 51.7×33.3×81.3 43.16
MCF8606GR 115 60 470 4.2 +33~+45 R290 5.3 77.8×33.3×81.3 64.88
NOTES :If the technical data has any changes, we will not notify you any longer.
