ATP Electronics TIF RX-1A - Parts & Controls; Getting Started; Installing Batteries

Installing Batteries
1. Remove the battery compartment door located on the bottom of the instrument as
shown above. Install batteries, Positive Polarity inwards (towards the unit).
(See figure 2).
GETTING STARTED
PARTS & CONTROLS
1 Sensing Tip
2 Tip Protector
3 Flexible Probe
4 Constant Power Indicator
5 Power On/Off
6 LED Leak Indicators
(RX-1A only)
7 Reset Button
(RX-1A Only)
8 High Sensitivity
(RX-1A Only)
9 Low Sensitivity
(RX-1A Only)
Fig.1
3
4
4
5
5
2
1
2
1
4
5
9
7
7
6
6
8
8
4
9
3
