ATS Super Stringer II - Parts List

10
PARTS LIST
4A TURNTABLE BUSHING
5 RUBBER FOOT
6A CAP SCREW- M8x25
8A SET SCREW- M5x6
24 KNOB
25 TENSION BAR
26 TENSION BAR CAP
27 DROP WEIGHT KNOB
28 FRONT WEIGHT
29 BACK WEIGHT
30 TENSION BAR DRUM
30A SET SCREW-
31 STRING GRIPPER DRUM
47 FLOATING CLAMP KNOB
48 SWING BOLT
49 RETURN SPRING
50 PIVOT PIN
51 RETAINING RING
78 CLAMP PLATE
79 CLAMP PLATE PAD
82 FRAME SUPPORT SHORT
82A FRAME SUPPORT TALL
83A TENSION BAR STOP SCREW
92 TURNTABLE
93 SUPPORT POST
94 SUPPORT POST PIN
95 SUPPORT POST PAD
161 WINDER BEARING
162 GRIPPER PIVOT PIN
163 PIVOT PIN RETAINER COLLAR
257 LOWER WINDER STAND
258 UPPER WINDER STAND
316 BASE
317 BASE COVER
MPFC FLOATING CLAMP
MRSG ROTATIONAL GRIPPER
70 5MM T-HANDLE HEX WRENCH*
98 BOX WRENCH- 10MM
108 UTILITY KNIFE
109 NEEDLE NOSE PLIERS*
MA STRINGER’S AWL*
MPSA PATHFINDER AWL*
* (NOT SHOWN)
OPTIONAL TOOLS & ACCESS
PART # DESCRIPTION TOOLS & ACCESSORIES
MBFC BADM FLOATING CLAMP
MPMC MACHINE COVER
MPG STARTING CLAMP
MPS CLEANING STONE
SGSM STRINGER'S MAT
