ATTACK PELLET Series - S1 X Burner: Electrical, Functional, and Parts Details; Electrical connection scheme of the burner IWABO VILLA - S1 X

1 brown
3 black
4 white
2 yellow-green
LEGEND-colour marking
Electrical connection scheme of the burner IWABO VILLA - S1X
1 - motor of feeder with thermal protecting switch
2 - plug connection for pellet feeder
3 - thermal fuse
4 - ventilator
5 - ignition spiral
6 - control board with green point
7 - photocell
8 - burner limit switch
9 - check of ventilator rounds
10 - connector sock plug
pellet burner IWABO VILLA - S1X
1
2
3
4
CONNECTION OF SOCK PLUG
front view
123
4
5
6
7
89101112
Brown
Yellow - Green
Black
White
3142
v
v
220V 0,5A
1
2
96
457
10
13
