THERMOSTAT
ENTER
< > EXIT
LANGUAGE
ENTER
< > EXIT
PELLETS TRIM
ENTER
< > EXIT
OP. TIME AUGER
ENTER
< > EXIT
TEST
ENTER
< > EXIT
Here you can choose the thermostat to be used: The external boiler
thermostat or the burner temperature sensor.
If using the temperature sensor, cut-in and cut-out temperatures
can be chosen from two options. These options will be accessible
after choosing the temp. sensor. The burner must always be
electrically connected to an overheat protector mounted on the
boiler.
Language selection is limited to Swedish and English.
Here you
adjust the amount of pellets fed by the auger at full operation.
When trimming the pellets infeed you need a bag and a fairly
precise scale. Upon accessing this parameter, you first encounter
Energy (kWh/kg)”, where you enter the pellet energy content.
This is followed by the display text “Mount bag”, and the pellet
feeder should be filled up to its outlet with pellets. Suspend a
bucket or bag from the outlet and push “M” button.
Now you will see a count-down on the display, while the pellet
feeder is running for 6 minutes. After this, enter the weight of the
pellets you obtained with the “+” and “-“ buttons and
confirm/save by pushing the “M” button.
Here you can see how long the pellet feeder has been operating.
This you can use for calculating energy consumption etc.
To be used for trouble-shooting. Here you can operate the
components automatically or manually.
= The most important parameter of control system!
Selection of thermostat:
Language selection:
Trimming of pellets infeed:
Operating time, feeder:
Test:
26
This function can be of a great help when trouble-shooting components.
In manual mode, each component can be tested separatelly by starting it with the „M“ button and
stopping it with „E“ button. Step forward to the desired component with the “+/-“ buttons. The
display shows them in following order:
(when testing the fan, the rpm displayed should stabilize at 2000);
(to be start/stop with the “M”/”E” buttons);
(activate with “M” and stop with “E”);
(push out with “M” and in with „E”. Here you can also see how many mA the drive consumes
during its operation; it should not exceed 1800mA- the limit for alarm "Scraper jamming" is
3000mA).
Other options displayed: current temperature if the temperature sensor is connected; current photocell
value; display lightning On/Off; closing of this application.
Fan
Pellet feeder
Ignition coil
Grate
