Auber Instruments Auberins KIT-GGP User Manual

- 16 -
Fig 20b. Grounding wire tapping. Green arrow indicates where to remove the original
grounding cable of the machine (green cable with yellow stripe). Then, tap the grounding
wire of the PID kit to the ground post on the socket. After that, plug the original grounding
wire of the machine to the piggyback connector.
Fig 20c. Back view of the controller box after tapping grounding wire. Red arrow indicates
where to install the grounding wire.
F. Connecting the stream control cable.
