14
CAT5E
WLI / WMI
300 m
Example 1: One input module connected
Maximum cable length: 300 meter
CAT5E
WLI
150 m
WMI
Example 2: Two input modules connected
Maximum cable length: 150 meter
CAT5E
WLI
450 m
WMI
ARJ03P
150 m
Example 3: Two input modules with junction box + external PSU connected
Maximum cable length: 600 meter (450 + 150)
