3
Introduction
6” High-end Slim Ceiling Speaker
The CELO6 is the 6” version of AUDAC’s CELO High-end Slim ceiling speaker series
with an RMS power of 60 Watt and Maximum power of 120 Watt, consisting of a 6”
aluminum cone woofer with 1” aluminum cone tweeter.
Due to its slim grill design with very thin border of only 1 mm and a limited grill depth
which extrudes from the ceiling surface by only 3.2 mm, these speakers will become
nearly invisible when mounted. To make them blend in even more, they can be painted
in the same colour as the surrounding surface. This elegant and unobtrusive grill is held
in place by means of powerful neodymium magnets, making assembly and disassembly
very simple, but still reliable enough for keeping the grill in place during the complete
lifetime of the loudspeaker.
When the grill is removed, it’s clear for anyone to see that the CELO speakers are made by
using only the highest quality materials, guaranteeing an unsurpassed sound experience.
One 1Aluminum cone tweeter is held in place by an acoustically optimized arm in front
of a 6” Aluminum cone woofer. Together with the crossover network which is made of
high-quality components, this results in true to nature sound reproduction for a warm
and detailed sound with an RMS power of 60 Watt.
To guarantee a lifetime stability, secure mounting and easy installation, the loudspeaker
connection is made using Gold plated spring clamp connectors. The mounting of the
loudspeaker into the ceiling should be done by a quick-fixing mechanism which can
be tightened by four screws. The front grill is held into place by neodymium magnets.

Other manuals for AUDAC CELO6

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the AUDAC CELO6 and is the answer not in the manual?

AUDAC CELO6 Specifications

Power and Sound IconPower and Sound
RMS power60 Watt
max power120 Watt
nominal impedance8 Ohm
sensitivity88 dB
sound pressure106 dB
frequency response55 Hz - 20 kHz
cross-over frequency3.0 kHz
Weight and Dimensions IconWeight and Dimensions
dimensionsØ 230 x 103 mm
cut-out measurementØ 210 mm
built-in depth100 mm
weight1, 5 Kg
shipping weight2, 1 Kg
