RS232 (serial connection interface):
For connection with home automation systems, or other remote control equipment
Connection Standard RS232
PIN 2 XMP44 TX
PIN 3 XMP44 RX
PIN 5 GND
Settings 19200 Baud
8 Bit
1 Stop bit
No parity
No Handshaking
RS232
The XMP44 has an RS232 and TCP/IP ports accepting the same commands. The complete
command set to control the XMP44 is available in the XMP44 commands user manual
which is freely downloadable on www.audac.eu
