29
Air cleaner
A round filter is employed instead of a flat filter
to achieve a larger filter surface area for more
air throughput in view of the different amount
of space available.
Furthermore, an additional intake air flap in the
air cleaner is opened as a function of load at
engine speeds as of 3,000 rpm to attain the
large volume of air required at full throttle. This
flap enables additional air to be drawn in from
the engine compartment and reduces the air
velocity in the air cleaner.
SSP282_018
SSP282_019
