Audi 2003 A8 - System Layout

52
System layout
Running Gear
SSP282_054
Design and operation of 4-level air
suspension are described in SSP 292.
Front information and
display and operating
unit control unit J685
Front axle
level sensors
Solenoid valve block
Rear axle
level sensors
Pressure
accumulator
Adaptive suspension
control unit
Rear axle
air suspension struts
Rear axle
acceleration sensors
Compressor
Control unit with
display in dash panel
insert J285
Front axle
air suspension struts
Front axle acceleration sensors
