8
A-pillar
The A-pillar is made of two cast shells
connected by rivets and welds.
The shells enclose the sill panel at the bottom
and the continuous roof frame at the top.
SSP282_029
Sill panel
Use is made for the sill panel of a 3-piece
extruded section.
The extruded section must be replaced in the
event of sill panel damage.
Depending on the nature of the damage,
either the entire section has to be replaced or
parts of it by way of three separating sleeves.
Body
SSP282_030
