Obtain and record radio anti-theft code for vehicles with coded radio.
See Caution for disconnecting Telematics battery --> Cylinder head, removing and installing
Disconnect battery Ground strap with ignition switched off.
Drain cooling system --> Cooling system, draining and filling.
Remove intake manifold from cylinder head. --> 24 - MULTIPORT FUEL INJECTION (MFI)
Remove ribbed belt and ribbed belt tensioner --> Ribbed belt, removing and installing.
Remove toothed belt from camshaft sprocket --> Toothed drive belt, removing, installing and
tensioning.
Fig. 155: Air Cleaner Cover
Courtesy of VOLKSWAGEN UNITED STATES, INC.
Remove air cleaner cover - arrow -.
Fig. 156: Disconnect Wires/Unplug Connectors From
Courtesy of VOLKSWAGEN UNITED STATES, INC.
Disconnect wiring connectors from:
1. EVAP canister pur
e re
ulator valve N80
