2. Mass Air Flow (MAF) sensor G70
3. Wastegate bypass regulator valve N75
Disconnect hoses 4...7.
Disconnect hose to secondary air injection pump motor - 8 -.
Move wires clear.
Unbolt air cleaner housing - 9 -.
Remove air cleaner.
Fig. 157: Disconnecting Connector At Camshaft Adjuster
Courtesy of VOLKSWAGEN UNITED STATES, INC.
Disconnect connector - arrow - at camshaft adjuster.
Fig. 158: Crankcase Breather Line, Secondary Air Combination Valve Line And Heat Shield
Courtesy of VOLKSWAGEN UNITED STATES, INC.
Remove crankcase breather line - 2 -.
NOTE:
Vacuum line to secondary air combination valve is clipped to underside of
air intake hose.
2005 Audi A4 Quattro
ENGINE 1.8 Liter 4-Cyl. 5V Turbo Engine Mechanical, Engine Code(s): AMB
1:01:01 AM Page 106
