Remove crankcase breather hose at cylinder head cover.
Remove line - 1 - on secondary air combination valve on cylinder head cover and heat shield - 3 -.
Move secondary air line slightly to one side.
Remove heat shield.
Fig. 159: Removing Bolts Of Oil Supply Line & For Turbocharger
Courtesy of VOLKSWAGEN UNITED STATES, INC.
Remove bolts - 1 - and - 2 - of oil supply line.
Remove bolts - 3 - for turbocharger.
Fig. 160: Disconnecting Connector At Coolant Temperature Sensor G2/G62
Courtesy of VOLKSWAGEN UNITED STATES, INC.
Disconnect connector - arrow - at coolant temperature sensor G2/G62.
2005 Audi A4 Quattro
ENGINE 1.8 Liter 4-Cyl. 5V Turbo Engine Mechanical, Engine Code(s): AMB
