Fig. 8: Air Cleaner Cover
Courtesy of VOLKSWAGEN UNITED STATES, INC.
Remove air cleaner cover - arrow -.
Fig. 9: Evaporative Emission Canister Purge Regulator Valve N80 And Air Duct
Courtesy of VOLKSWAGEN UNITED STATES, INC.
Remove bolts - arrows -.
Disengage EVAP canister purge regulator valve N80 - 1 - from air duct - 2 -.
Remove both screws - arrows - for air duct - 2 -.
Remove front bumper: -->
63 BUMPER
63 - BUMPERS for CABRIOLET
Vehicles with auxiliary heater
2005 Audi A4 Quattro
ENGINE 1.8 Liter 4-Cyl. 5V Turbo Engine Mechanical, Engine Code(s): AMB
1:00:55 AM Page 7
