Unbolt sound insulation holder.
Fig. 13: Removing Air Duct In Front Of Charge Air Cooler
Courtesy of VOLKSWAGEN UNITED STATES, INC.
Remove air duct in front of charge air cooler - arrows -.
Place drip tray VAG1306 under engine.
Fig. 14: Pulling Retaining Clip For Engine Coolant Temperature (ECT) Sensor G2 Off Lower Coolant
Hose And Drain Coolant From Radiator
Courtesy of VOLKSWAGEN UNITED STATES, INC.
Pull retaining clip - 1 - for Engine Coolant Temperature (ECT) sensor G2 - 2 - off lower coolant hose and
drain coolant from radiator.
Remove lower coolant hose from radiator.
2005 Audi A4 Quattro
ENGINE 1.8 Liter 4-Cyl. 5V Turbo Engine Mechanical, Engine Code(s): AMB
1:00:55 AM Page 9
