Fig. 15: Disconnecting Coolant Hose From Oil Cooler
Courtesy of VOLKSWAGEN UNITED STATES, INC.
Disconnect coolant hose from oil cooler - arrow - and drain remaining coolant.
Fig. 16: Removing Air Hose To Charge Air Cooler At Bottom Left Of Lock Carrier
Courtesy of VOLKSWAGEN UNITED STATES, INC.
Remove air hose - arrow - to charge air cooler at bottom left of lock carrier.
Fig. 17: Removing Lower Air Hose Between Turbocharger And Lock Carrier
Courtesy of VOLKSWAGEN UNITED STATES, INC.
2005 Audi A4 Quattro
ENGINE 1.8 Liter 4-Cyl. 5V Turbo Engine Mechanical, Engine Code(s): AMB
