55 HOOD, LIDS
55 - HOOD, LIDS for CABRIOLET
Fig. 22: Removing Top Coolant Hose From Radiator & Disconnecting Connectors For Left/Right Airbag
Sensor
Courtesy of VOLKSWAGEN UNITED STATES, INC.
Remove top coolant hose from radiator - 1 -.
Disconnect connectors - 2 - for left and right airbag sensor.
Fig. 23: Unbolting Lock Carrier On Left/Right
Courtesy of VOLKSWAGEN UNITED STATES, INC.
Unbolt lock carrier on left and right - arrows -.
Remove lock carrier.
Vehicles with automatic transmission
NOTE:
A second technician is required to remove the lock carrier.
Place lock carrier in a secure position.
2005 Audi A4 Quattro
ENGINE 1.8 Liter 4-Cyl. 5V Turbo Engine Mechanical, Engine Code(s): AMB
1:00:55 AM Page 13
