Place drip tray underneath.
Fig. 24: Disconnecting ATF Lines
Courtesy of VOLKSWAGEN UNITED STATES, INC.
Disconnect ATF lines - arrows -.
Unbolt bracket for ATF lines on left of engine.
Vehicles up to 06.03
NOTE:
Observe the rules for cleanliness when working on an automatic
transmission:
-->
37 - AUTOMATIC TRANSMISSION - CONTROLS, HOUSING for 5 SPD.
AUTOMATIC TRANSMISSION 01V
37 - AUTOMATIC TRANSMISSION - CONTROLS, HOUSING for 5 SPD.
AUTOMATIC TRANSMISSION 01V FRONT AND ALL WHEEL DRIVE -
INTERNAL COMPONENTS, SERVICING
37 CONTROLS, HOUSING for AUTOMATIC TRANSMISSION 09L,
FOUR-WHEEL DRIVE
CAUTION: Fuel system is under pressure! Before opening system, place rags around
the connection point. Then release pressure by carefully loosening
connection.
2005 Audi A4 Quattro
ENGINE 1.8 Liter 4-Cyl. 5V Turbo Engine Mechanical, Engine Code(s): AMB
1:00:55 AM Page 14
