Audi AMB - Page 48

7 - Hole in fende
r
Removing
Vehicles with auxiliary heater
Fig. 60: Removing Bolts Securing Exhaust Pipe Of Auxiliary/Additional Heater To Sound Insulation
Courtesy of VOLKSWAGEN UNITED STATES, INC.
 Remove bolts - arrows - securing exhaust pipe of auxiliary/additional heater to sound insulation.
All models
Fig. 61: Removing Sound Insulation
Courtesy of VOLKSWAGEN UNITED STATES, INC.
 Remove sound insulation - arrows -.
2005 Audi A4 Quattro
ENGINE 1.8 Liter 4-Cyl. 5V Turbo Engine Mechanical, Engine Code(s): AMB
