For generator, power steering pump and air conditioning compressor
Removing and installing --> Bracket for generator, power steering pump and air conditioning
compressor, removing and installing
6 - 40 Nm
7 - Generator
Removing:
See Caution before beginning repairs on electrical system --> Engine, disassembling and assembling
Disconnect battery Ground (GND) strap
Loosen ribbed belt and remove from generator --> Ribbed belt, removing and installing.
Loosen bolted connection at top and bottom.
Swivel generator to side slightly and disconnect electrical connectors.
Remove generator.
8 - 20 Nm
9 - 40 Nm
10 - 20 Nm
11 - Power steering pump
Removing and installing: --> 48 - STEERING
12 - 40 Nm
13 - Air conditioning compressor
When installing, pay attention to dowel sleeves
14 - 20 Nm
15 - Vibration damper/pulley
Can only be installed in one position Installing vibration damper/pulley
16 - Collared bolt, 10 Nm + 90 ° * See note
17 - Idler wheel
2005 Audi A4 Quattro
ENGINE 1.8 Liter 4-Cyl. 5V Turbo Engine Mechanical, Engine Code(s): AMB
1:00:56 AM Page 40
