 Carefully engage in center section of toothed belt guard when installing
5 - Toothed belt
 Mark direction of rotation with chalk or felt-tip pen before removing
 Check for wear
 Removing --> Toothed drive belt, removing, installing and tensioning
 Installing (adjusting valve timing)
6 - Idler wheel
7 - 27 Nm
8 - 65 Nm
 Use counterhold 3036 to loosen and tighten
9 - Camshaft sprocket
 For exhaust camshaft
 To remove and install first remove toothed belt --> Toothed drive belt, removing, installing and
tensioning
 Installed position Installed position of camshaft sprocket
10 - Tensioning roller
11 - Washer
12 - Toothed belt tensioner
13 - O-ring
 Replace
 Coat with coolant G 012 A8 D before installing
14 - Coolant pump
 Removing and installing --> Coolant pump, removing and installing
15 - 15 Nm
16 - Crankshaft toothed belt sprocket
 Contact surface between toothed belt sprocket and crankshaft must be free of oil
 Removin
g
and installin
g
Removing and installing crankshaft toothed belt sprocket
2005 Audi A4 Quattro
ENGINE 1.8 Liter 4-Cyl. 5V Turbo Engine Mechanical, Engine Code(s): AMB
