Fig. 131: Pulling Out Pilot Needle Bearing Using Kukko 21/1 And Kukko 22/1
Courtesy of VOLKSWAGEN UNITED STATES, INC.
 Pull out pilot needle bearing using Kukko 21/1 and Kukko 22/1.
Installing
Fig. 132: Driving In Needle Bearing Using Drift VW 207 C
Courtesy of VOLKSWAGEN UNITED STATES, INC.
 Drive in with drift VW207C or centering mandrel 3176.
 Letterin
g
on pilot needle bearin
g
must be visible when installed.
2005 Audi A4 Quattro
ENGINE 1.8 Liter 4-Cyl. 5V Turbo Engine Mechanical, Engine Code(s): AMB
1:01:00 AM Page 86
