Audi Q3 - Installation Procedure Steps

2
Installation procedure
1
1.汽车中控图
Installation procedure
2.Dismantlingairoutofairconditionandtakeout
4.Takeorigianlscreenandtakeoutplug
6.Dismantlingthepanelofaircondition
7.TakingouttheCANplugoftheairconditionpane,lthenconnecttotheCANcableofthe
powerline.
8 .Connectourpoweradapter
cabletooriginalCDpowerplug
10.settheminispeakernearthedrivingareaandinsertthe
minispeakerplugright.
1 2 .Arrangethecablesofthescreenwellonthecenterconsole
boardandresettheoriginalCD
14.Installthescreen,insertthecableplug
andtightenthescrews
9 .Connectthehostplugcorrectlyandfixthehostwell
1.Theoriginalcenterconsole
3.Dismantlingthescrews
ofscreen
5.UsingCDkeytodismantleCDplayerand
takeoutplug
1 1 .Installtheexternalmic
atAdrivingarea
1 3 resettheairconditionpanel
15.Resettheairconditionventpanel.
