AUDIO MASTER M7 USB - TYPICAL CONNECTION DIAGRAM; Mixer Features and Capabilities

7 Channel Mixer 5 XLR Balanced Mic / Line -1 Stereo Line (M7 USB)
4 Channel Mixer 2 XLR Balanced Mic / Line -1 Stereo Line (M4 USB)
Individual Gain, Bass, Mid, High,Aux, Pan Controls
Built in Effect Processor
Stereo RCA Outputs for Recording
TRS Jack Outs
Main Slide Control (L+R), Phones
Individual Echo, Peak LEDs on each inputs
Phantom with LED for condenser mics
Channel Slides for smooth operation
5 inserts for Microphones (M7 USB)
2 inserts for Microphones (M4 USB)
6 x 2 Segment LED Level meter
Delay, repeat, Effect Send & AUX Controls
Congratulations on your purchase of a F Series Compact Professional Live
Mixer by Proton Audio. Please take some time to carefully read the below
instructions to get the optimum of your mixer.
PLEASE READ BEFORE USING APPLIANCE, IMPORTANT WARNING & SAFETY INSTRUCTIONS!
L
I
S
T
E
D
R
CAUTION
RISK OF ELECTRICAL SHOCK DO NOT OPEN!
2
TYPICAL CONNECTION DIAGRAM
9
