Characteristic Specifications Supplemental Information
96 APx52x and 58x Families General and Environmental
ENVR
EMC
Complies with Directive 2004/108/EC,
IEC 61326-1:2005, EN 61326-1:2006.
Radiated and conducted emissions
are within Class B limits of CISPR 11.
IEC 61326-2-1:2005 Section 5.2.401
is applied (controlled EM environ-
ment) for options “DSIO” and “PDM”.
Complies with Directive 1995/5/EC
if option “BT” (Bluetooth) is installed.
Emissions and immunity levels are influ-
enced by the quality of interface and sig-
nal cables attached to the unit.
Compliance was demonstrated using
Audio Precision cables
Safety
Complies with Directive 2006/95/EC,
IEC 61010-1:2001, EN 61010-1:2001,
CAN/CSA-C22.2 No. 61010-1-04, and
UL Std No. 61010-1 (2nd Edition).
Equipment Class I,
Installation Category II,
Pollution Degree 2,
Measurement Category I
Dimensions (W x H x D)
432 x 129 x 467 mm
[17.0 x 5.1 x 18.4 in]
3U rack mount kit available.
D is 475 mm [18.7 in] if rear panel option
keys or Option AMC is installed.
Weight
Ranges from
10.7 kg [23.5 lbs]
to
11.8 kg [26 lbs]
Weight depends upon model and
installed options
