Characteristic Specifications Supplemental Information
38 APx517 B Series Acoustic Analyzer: Specifications
Amplitude Range 0 to 48.08 Vpp
Amplitude Accuracy ±0.06 dB [±0.70%]
Residual IMD {notes 1,2,3} 0.010% [-80 dB]
Multi-tone, Wave File Playback
Sample Rate Range (SR) 8 kS/s to 108 kS/s, and
175 kS/s to 192 kS/s
Operation from 109 kS/s to 175 kS/s is
possible, but with degraded flatness
Maximum File Size 256 Msample
Amplitude Range 0 to 48.08 Vpp ".Wav" file must peak at digital full scale
to obtain selected amplitude
Flatness (1 kHz ref)
SR = 175 kS/s to 192 kS/sec Typically < 0.012 dB to 20 kHz
SR = 8 kS/s to 108 kS/s Typically < 0.04 dB to 20 kHz;
max frequency limited to 0.45 * SR
Spurious Content Typically < -100 dB, 20 Hz to 20 kHz
Output Equalization
Arbitrary 30-pole output filter
Impedance Measurement
Accuracy 1% for resistive loads 4 to 16 ,
20 Hz to 20 kHz
2% for resistive load 2 to 4 ,
20 Hz to 20 kHz
Vdriver Maximum Input Voltage
Balanced 40 Vpk (80 Vpp), differentially
Maximum Output Current
6.0 Apk 35 W into 2
