Characteristic Specifications Supplemental Information
46 APx517 B Series Acoustic Analyzer: Specifications
Frequency Measurement
Range < 5 Hz to 90 kHz
Accuracy ±(0.0003% + 100 Hz) Vin must be 5 mV
Resolution 6 digits
Phase Measurement
Ranges -90 to +270, ±180, or 0 to 360 deg
Accuracy ±0.2 deg, 5 Hz to 5 kHz;
±0.8 deg, 5 kHz to 20 kHz;
±2.0 deg, 20 kHz to 50 kHz
Vin must be 5 mV with DC coupling,
both channels. Accuracy degrades
below 50 Hz with AC coupling
Resolution 0.001 deg
DC Voltage Measurement
Input Ranges 0.25 V to 25 V, 10 dB steps ±40 Vdc maximum in 25 V range.
Accuracy
250 mV and 800 mV ranges ±(0.7% reading + 1 mV)
2.5 V-8 V ranges ±(0.7% reading + 0.1% range)
Normal Mode Rejection Typically > 90 dB, 20 Hz to 20 kHz
