Audio Precision B Series User Manual

Characteristic Specifications Supplemental Information
62 APx HDMI+ARC I/O Module for B Series: Specifications
HDMI
Revision
1.3a + ARC. ARC (Audio Return Channel) imple-
mented per HDMI 1.4a
Device Connections
SOURCE Typically connects to the sink input of
a DUT.
The video is an internally generated sin-
gle color screen or the signal applied to
the AUX IN connector. The audio is
internally generated: see “Embedded
Output Signal Related” under “DIGITAL
I/O” for typical waveforms and parame-
ters.
ARC Tx / AUX IN HDMI ARC Tx configuration: Typically
connects to an HDMI source that
accepts ARC audio.
HDMI Source configuration: typically
connects to an external source of
video to be included in the Source out-
put signal.
Generates and transmits audio across
ARC, per HDMI 1.4a. HDMI source
should not transmit video.
Incoming audio is ignored. Incoming
video is passed to HDMI Source in “pass
through” mode.
ARC Rx / AUX OUT HDMI ARC Rx configuration: Typically
connects to an HDMI sink that pro-
duces ARC audio.
HDMI Sink configuration: Typically
connects to an independent monitor-
ing device.
HDMI ARC Rx configuration: Receives
and analyzes audio across ARC, per
HDMI 1.4a. No video is transmitted.
HDMI Sink configuration: Contains video
and audio sent to Sink input.
SINK Typically connects to the source out-
put of a DUT.
The embedded and encoded audio sig-
nal components are recovered for analy-
sis.
Hardware Interface
HDMI Type A
EDID
256-byte EEPROM on both Sink and
ARC TX / AUX IN connectors.
