Characteristic Specifications Supplemental Information
APx HDMI+ARC I/O Module for B Series: Specifications 63
HDMI
CEC (ARC connectors)
HDMI ARC Tx configuration: ARC
CEC implementation per HDMI 1.4a.
HDMI ARC Rx configuration: ARC
CEC implementation per HDMI 1.4a.
ARC link can be negotiated or forced on.
User can manually send a CEC ping
or arbitrary CEC message to any of
the standard logical addresses. An
indicator confirms the receipt of an
ACK (acknowledged) message from
the messaged device.
CEC (HDMI Sink, Source
Connectors)
HDMI Source configuration: CEC
implementation per HDMI 1.4a.
Also, user-selectable CEC pass-
through from AUX IN to Source.
HDMI Sink configuration: CEC
implementation per HDMI 1.4a.
Also, user-selectable CEC pass
through from Sink to AUX OUT.
User can manually send a CEC ping
or arbitrary CEC message to any of
the standard logical addresses. An
indicator confirms the receipt of an
ACK (acknowledged) message from
the messaged device.
Color Support
24-bit, 30-bit, 36-bit (Deep Color)
Max Video Rate
1080p
ARC DIGITAL I/O
ARC DIGITAL OUTPUT RELATED:
Formats
Signal level, single mode 0.5 Vpp typical Output R is 55 typical.
Signal level, common mode 0.4 Vpp typical Output R is 30 typical.
Sample Rate (SR) Range
27 kS/s–200 kS/s Usable over the extended range of
16 kS/s to 216 kS/s with degraded
waveform fidelity, accuracy, and jitter
Sample Rate (SR) Accuracy
±0.0003% [3 PPM]
Channel Status Bits
Full implementation per IEC60958 Automatically set or manual override,
hex or plain English.
User Bits
Fully settable Hex.
Validity Flag
Set to 0, all channels
Residual Jitter
1,2
<1.0 ns typical
